Fanvil i564W SIP Indoor Station

The Fanvil i564W SIP Indoor Station is a premium 7-inch indoor video intercom designed for villas, apartments, residential communities, and commercial buildings. It features a 7-inch IPS capacitive touchscreen with 1024 × 600 resolution, a tactile volume-control knob, two shortcut buttons, a powerful 5 W multimedia speaker, smart noise cancellation, and voice pickup up to approximately 5 metres. The i564W supports 2.4 GHz Wi-Fi 6, Bluetooth/BLE key functions, two 10/100 Mbps Ethernet ports, SIP 2.0 over UDP/TCP/TLS, H.264 and optional H.265 video decoding up to 1080p, G.722/Opus HD audio, full-duplex communication with AEC, one-touch family calling, scheduled DND, customized ringtones, remote door unlocking, and message sending/receiving. For security and automation integration it provides 8 alarm inputs, 1 short-circuit output, 1 doorbell input, RS-485 and a TF-card slot supporting up to 128 GB, while power can be supplied through IEEE 802.3af PoE or 12 VDC/2 A. The related Fanvil i554 / i554W provides a cost-effective 7-inch indoor-station option using the same 1024 × 600 capacitive touchscreen format. It includes a 2 W speaker, 8 alarm inputs, one short-circuit output, doorbell input, RS-485, 10/100 Mbps Ethernet and IEEE 802.3af PoE or 12 VDC power; the i554W additionally adds 2.4 GHz Wi-Fi 6, making it suitable for retrofit projects where network cabling is limited. The compact Fanvil i503W SIP Indoor Station takes a different approach for difficult retrofit installations: it has a 2.8-inch 320 × 240 IPS display, five programmable physical buttons, 5 W speaker, dual-band 2.4/5 GHz Wi-Fi 6 and a built-in 2600 mAh rechargeable battery. It supports SIP 2.0, H.264, G.722/Opus HD audio, remote door unlocking, one-touch family calls and full-duplex hands-free communication, and is powered/charged through 5 VDC/2 A, making it especially useful where fixed PoE or Ethernet wiring is impractical. VEGA Digital IT Solutions LLC supplies and integrates the Fanvil i564W, i554, i554W, i503W and related Fanvil SIP indoor stations across Dubai and the UAE. VEGA Digital can connect these indoor stations with Fanvil SIP door phones and video intercoms, IP-PBX platforms such as 3CX/Asterisk-compatible systems, electric locks, door contacts, alarm sensors, RS-485 devices, PoE switches, Wi-Fi networks and structured CAT6 infrastructure. System installation includes site survey, model selection, wall-box and mounting preparation, PoE or DC power design, Ethernet/Wi-Fi configuration, SIP extension creation, indoor/outdoor station pairing, BLE access setup, alarm-input programming, RS-485 integration, door-release configuration, family-call and DND setup, TF-card configuration, audio/video optimization, testing, commissioning and future expansion, providing a complete Fanvil smart video-intercom and access-control solution for residential and commercial projects across Dubai.
