DaoSafe DS401FS

The DaoSafe DS401FS Canopy Full Height Turnstile is a high-security pedestrian access-control solution designed for exposed or demanding locations such as industrial facilities, construction sites, stadiums, embassies, government compounds, oil and gas sites, logistics centres and transport facilities. Its distinguishing feature is the integrated solid rain-protection canopy, which protects the mechanism from weather and also makes climbing over the turnstile more difficult. DaoSafe offers 304 stainless steel as standard with 316 stainless steel available, and the DS401FS can be configured with either 120° three-section or 90° four-section rotors. Published specifications include approximately 1460 × 1460 × 2300 mm dimensions, 646 mm passage width, 300 kg weight, 30 persons/minute flow rate, 10-million-cycle MCBF, 110/220 VAC 50/60 Hz supply, 24 VDC operating voltage, around 40 W power consumption, and -15°C to +60°C operating temperature. Single-direction or bi-directional operation is selectable, while red/green LED indicators display passage status. Other functions include an automatic hydraulic buffer for quieter rotation, automatic relocking after an adjustable delay, anti-tailgating one-person-per-rotation control, manual override and automatic rotor release during power failure for emergency evacuation. The related DS402FS expands the same canopy-protected full-height platform into a double-lane configuration, making it suitable for sites that require higher pedestrian capacity while maintaining strict physical access control. DaoSafe specifies an approximately 2200 × 1460 × 2300 mm enclosure with two 670 mm lanes, 304 stainless-steel construction, 120° three-section or 90° four-section rotors, approximately 500 kg net weight, 10-million-cycle MCBF, 24 VDC operation and 40 W power consumption. It provides separate LED indications for the two passages and supports the same single- or bi-directional operating modes, automatic reset, hydraulic buffering, emergency release and third-party access-control integration.In practical project selection, DS401FS is the single-lane canopy model, ideal where one tightly controlled passage is sufficient, while DS402FS is the dual-lane canopy model for sites requiring greater simultaneous pedestrian handling. DaoSafe also offers the DS401FS in customized finishes including black, red and blue painted versions, allowing the equipment to better match architectural or corporate design requirements. For VEGA Digital IT Solutions LLC as an organized DaoSafe partner and system integrator across the Middle East, DS401FS and DS402FS can be implemented as complete high-security entrance-management systems rather than stand-alone mechanical turnstiles. Installation can begin with site survey, pedestrian-flow and emergency-egress planning, followed by reinforced concrete foundation preparation, accurate frame alignment and anchoring, 110/220 VAC power provision, low-voltage and Cat6 cabling, weather-protected containment, reader mounting and integration through dry contact, relay or RS485. DaoSafe supports integration with third-party RFID/smart-card readers, fingerprint terminals, facial-recognition devices, biometric readers, QR/barcode systems, counters and other access-control equipment. VEGA Digital can then commission passage direction, access permissions, LED status indication, automatic reset timing, anti-tailgating behaviour, emergency power-off release and centralized attendance or visitor-management integration, followed by full testing and operator training. This provides a complete DaoSafe DS401FS/DS402FS outdoor full-height access-control solution for factories, stadiums, construction sites, logistics centres, government facilities and high-security developments throughout Dubai, the UAE and the wider Middle East.
