VANTAGE VP-PM5040SC/DC-SGT3

The VANTAGE VP-PM5040SC/DC-SGT3 Swing Gate Barrier is a heavy-duty motorized automatic entrance-management system designed for corporate offices, commercial towers, hotels, banks, government facilities, universities and premium reception areas where fast, controlled pedestrian passage and modern aesthetics are required. VANTAGE offers the platform in single-core and dual-core configurations with bidirectional operation, with optional passage heights of approximately 900 mm or 1200 mm and passage widths of approximately 600 mm or 900 mm. Key features include LED status indication, adjustable passage timeout, automatic barrier reset after each authorized user, RFID or biometric-reader integration through a normally-open input, emergency fail-safe operation and durable SS304 stainless-steel construction with IP44 protection. The VP-PM5040SC/DC-SGT3 is therefore suitable for standard pedestrian lanes as well as wider accessible lanes, and its modular single/dual-core architecture allows multiple units to be combined into coordinated multi-lane entrance systems. The related VANTAGE models allow VEGA Digital to match the gate to different pedestrian-flow and security requirements. The V-PM4240SC/DC-SGT3 provides a standard ≤600 mm lane with optional ≤900 mm, approximately 35–40 persons/minute throughput, 0.5–1.5 second opening/closing, a 150 W DC brushless motor, six pairs of infrared safety sensors and a service life of at least 10 million cycles; it operates at 24 VDC from a 100–240 VAC supply and uses an AISI 304 stainless-steel/IP54 chassis. The V-PM4500SC/DC-SGT3 adds selectable single-direction, bidirectional, always-free and always-locked modes, fiberglass swing panels, LED direction indication and dual anti-clipping protection using photocell and mechanical methods; the published SC datasheet specifies 600 mm or optional 900 mm passage, about 30 persons/minute, brushless servo motor, 100–240 VAC supply, 24 VDC operation and IP54/IP56 options. The V-PM4200SC/DC-SGT3 provides 600/900 mm lanes, 35–40 persons/minute, 0.5–0.8 second movement, five IR sensor pairs and more than 5 million cycles, while the higher-specification V-PM4700SC/DC-SGT3 expands the lane options to 600, 900 or 1300 mm, uses 14 IR sensor pairs, a 55 W brushless drive and more than 10 million cycles, making it particularly suitable for wider accessible lanes and more demanding entrance applications. For VEGA Digital IT Solutions LLC’s VANTAGE projects across Dubai and the wider UAE, these swing gates can be delivered as a complete entrance-control system beginning with site survey, pedestrian-flow analysis, selection of the required single/dual-core configuration and 600/900/1300 mm lane width, followed by floor preparation, mechanical anchoring, 100–240 VAC power supply, 24 VDC control wiring, network cabling, infrared-sensor alignment and fire-alarm/emergency-release integration. VEGA Digital can integrate the gates with RFID and smart-card readers, fingerprint terminals, facial-recognition devices, QR-code readers, employee attendance systems, visitor-management platforms and centralized access-control software, using NO/NC/COM relay interfaces and RS232/RS485 where supported. Final commissioning can include swing-panel alignment, opening/closing speed adjustment, infrared anti-clipping and anti-tailgating checks, timeout and automatic-reset configuration, credential testing, fail-safe/fail-lock verification, fire-alarm evacuation testing and end-user training, providing a complete VANTAGE pedestrian entrance-management solution for corporate offices, hotels, banks, schools, government facilities and premium commercial developments throughout Dubai and the UAE. VANTAGE specifically identifies swing gates as suitable for multi-lane entrance management and integration with RFID, QR and biometric authentication systems.
