ACTpro-120 Controller RS485 2A 12VDC PS

The Vanderbilt ACTpro-120 Controller RS485 with 2A 12VDC Power Supply is a single-door expansion module designed for use within the Vanderbilt ACTpro access control platform. It enables an additional door to be added to compatible ACTpro controllers such as the ACTpro-1500 and ACTpro-1520, communicating with the main controller through an RS485 connection. The ACTpro-120 includes an integrated 12V DC, 2A power supply, helping simplify installation by providing power for the door station and connected access control devices. The ACTpro-120 offers comprehensive door-control functionality, including a main relay rated at 5A/50V AC and an auxiliary relay rated at 1A/50V AC, request-to-exit input, door monitoring, break-glass monitoring, voltage monitoring, tamper monitoring and AC power-status monitoring. It supports Vanderbilt ACTpro readers using technologies such as 125 kHz RFID, MIFARE Classic and MIFARE DESFire EV1, and can accommodate both Clock & Data and Wiegand reader interfaces, including entry and exit reader configurations. Additional features include reader current limiting and short-circuit protection, status LEDs and interlocking functionality. The integrated power supply shares its available 2A output between the door station, battery charging, readers and locking devices, with Vanderbilt recommending that up to approximately 1.5A be allocated to locks and readers. VEGA Digital IT Solutions LLC provides professional supply, installation and system integration of Vanderbilt ACTpro-120 access control solutions in Dubai and across the UAE. As a trusted supplier and system integrator, VEGA Digital can integrate the ACTpro-120 with compatible Vanderbilt ACTpro controllers, card readers, electromagnetic locks, electric strikes, door contacts, exit buttons, request-to-exit sensors, emergency break-glass units, backup batteries and centralized access-control software. Our services can include system design, RS485 network configuration, reader and lock wiring, controller addressing, access-level programming, power-supply configuration, testing, commissioning, troubleshooting and future door expansion. By combining Vanderbilt’s scalable ACTpro architecture with VEGA Digital’s integration expertise, customers can deploy a reliable, secure and expandable access control solution for corporate offices, commercial buildings, warehouses, educational facilities and other secured premises throughout Dubai.
