HIKVISION DS-K1T8003EF

The HIKVISION DS-K1T8003EF Value Series Fingerprint Access Control Terminal is a compact access-control and time-attendance device designed for offices, shops, warehouses, schools and other small-to-medium installations. It features a 2.4-inch LCD-TFT display, an optical fingerprint sensor and a built-in 125 kHz EM card reader, supporting up to 1,000 users, 1,000 fingerprint templates, 1,000 cards and 100,000 event records. Fingerprint verification supports both 1:1 and 1:N matching with recognition in under 1 second. The terminal supports 10/100 Mbps TCP/IP, ISUP communication, Hik-Connect remote door opening, tamper alarm and standalone attendance reporting, while onboard interfaces include lock control, exit button, door-contact input, USB and network connectivity. It operates from 12 VDC / 1 A and can work as both a standalone attendance terminal and a single-door access-control device. The DS-K1T8003 Series includes three principal models for different credential requirements. DS-K1T8003F is the fingerprint-only version, supporting 1,000 fingerprints and 100,000 events without an integrated card reader. DS-K1T8003EF combines fingerprint authentication with EM proximity cards, offering an EM reading range of approximately 0–3.5 cm. DS-K1T8003MF provides the same fingerprint and attendance platform but replaces the EM reader with a 13.56 MHz M1/MIFARE card reader, supporting up to 1,000 M1 cards with an approximate reading range of 0–5 cm. All three versions share the 2.4-inch display, optical fingerprint technology, TCP/IP networking, USB support, lock/exit/door-contact interfaces, 12 VDC power and standalone USB attendance-report export, allowing projects to select fingerprint-only, EM-card or M1-card authentication while maintaining one consistent Hikvision platform. VEGA Digital IT Solutions LLC provides the HIKVISION DS-K1T8003F, DS-K1T8003EF and DS-K1T8003MF Value Series terminals as a professional vendor, supplier and system integrator across Dubai and the UAE. VEGA Digital can integrate these terminals with electromagnetic locks, electric strikes, door contacts, request-to-exit buttons, emergency break-glass units, power supplies, TCP/IP network infrastructure and Hikvision access-control or attendance platforms. Our services include site survey, model selection, fingerprint and card enrollment, network configuration, door-lock and sensor wiring, attendance-rule setup, user and access-level programming, Hik-Connect configuration, testing, commissioning, troubleshooting and future system expansion. This makes the DS-K1T8003 Series a practical and cost-effective solution for small offices, retail locations, warehouses, schools, clinics and commercial facilities requiring fingerprint-based access control and attendance management across the UAE.
